Small Road Blocker
| Length | 500 – 700 mm |
| Movement Part Sheet Type | ST37 Steel Quality |
| Moving Part | Blasting + Powder Coating |
| Upper Sheet | 10 mm |
| Front Sheet | 3 mm |
| Side Sheet | 4 mm |
| İnner Supporter | 4 mm |
| Connection Points | M8X15 İmbus Countersunk Head Screws Stainless |
| Operating Speed | 4 – 6 sec. |
| Control Panel | A-GA Board |
| System Security Support | Loop Sensor |
| Engine Power | 1,5-2.2-3 KW |
| Movement Mechanism | Hydraulic |
| Min. Operating Pressure | 40 bar / 580 psi |
| Max. Operating Pressure | 60 bar / 870 psi |
| Hydraulic Hose | R2 3/8 330 Bar |
| Hydraulic Oil | 32/46/68 |
| Unit Operating Voltage | 220/380 V ( AC) |
| Operating Temperature | -25 °C / +50 °C |
| Manually | Ball Valve |
| Can be connected to any kind of Access control system | License Plate Recognition, Card Reader,etc. |
| OPTIONAL | |
| Manual Lifting | Hand Pump |
| Power Outage | Accumulator Support |
| Warning Equipment | Flasher / Traffic Lamp |
| E.F.O. Circuit For Emergency Lifting | Yes 2 sec. |
| Control Panel | PLC (Programmable Logic Controller) |
| System Security Support | Safety Photocell |
| Hydraulic System Heating- Cooling | |
| Water Drain Pump | |
| Protection Class | IP67 |
| Product Certificates | CE, Turkish Goods Certificate |
| Quality Certificates | ISO (20000-1:2011, 9001:2015,10002:2018, 14001:2015), OHSAS (18001:2007) |
