Sharp PN-HW751
DISPLAY
| Panel Technology | TFT with Edge LED backlights |
| Active Screen Area (W x H) [mm] | 1,781.8 x 1,002.2 |
| Screen Size [inch/cm] | 75 / 189 |
| Aspect Ratio | 16:9 |
| Pixel Pitch [mm] | 0.429 x 0.429 |
| Brightness [cd/m²] | 400 |
| Contrast Ratio (typ.) | 1200:1 |
| Viewing Angle [°] | 178 horizontal / 178 vertical (typ. at contrast ratio 10:1) |
| Colour Depth [bn] | 1.073 (10bit) |
| Response Time (typ.) [ms] | 8 |
| Panel Refresh Rate [Hz] | 60 |
| Haze Level [%] | Standard (3) |
| Supported Orientation | Landscape; Portrait |
RESOLUTION
| Native Resolution | 3840 x 2160 |
| Supported Resolutions | 1024 x 768;1280 x 1024;1280 x 720;1280 x 800;1280 x 960;1360 x 768;1400 x 1050;1440 x 900;1680 x 1050;1920 x 1080;3840 x 2160;4096 x 2160;640 x 480;800 x 600;848 x 480 |
CONNECTIVITY
| Input Video Analogue | 1 x VGA |
| Input Video Digital | 3 x HDMI (with HDCP) |
| Input Audio Analogue | 1 x 3,5 mm jack |
| Input Audio Digital | 3 x HDMI |
| Input Control | LAN 100Mbit; RS232 |
| Input Data | 1 x USB Medaplayer |
| Output Audio Analogue | 1x Cinch (L/R) |
ELECTRICAL
| Power Consumption Eco/max. [W] | 255 (max.) |
| Power Savings Mode [W] | < 0.5; < 1 (Networked Standby) |
| Power Management | VESA DPMS |
| Power Supply | 100-240 V AC; 50/60 Hz; internal |
ENVIRONMENTAL CONDITIONS
| Operating Temperature [°C] | +0 to +40 |
| Operating Humidity [%] | 20 to 80 |
| Storage Humidity [%] | 10 to 90 |
| Storage Temperature [°C] | -20 to 60 |
MECHANICAL
| Dimensions (W x H x D) [mm] | 1,680 x 959 x 65.5 |
| Weight [kg] | 55 |
| Bezel Width [mm] | 15 (bottom); 15 (left and right); 15 (top) |
| VESA Mounting [mm] | 4 holes; 600 x 400 (FDMI); M6 |
| Packaging Dimensions (W x H x D) [mm] | 1,832 x 1,283 x 280 |
| Packaging Weight [kg] | 69 |
GREEN FEATURES
| Energy Efficiency | Energy consumption: 240 kWh/1000 h; Energy efficiency class: G; LED backlight |
ADDITIONAL FEATURES
| Special Characteristics | ASCII Control Commands; CEC Support; Removable Logo; Scheduler; USB Media Player |
| Colour Versions | Black Front Bezel, Black Back Cabinet |
| Safety and Ergonomics | CE; EAC; RoHS |
| Audio | Integrated Speakers (2 x 10 W) |
| Shipping Content | 2x AAA batteries; CD-ROM (User Guides/Manuals); Display; Logo Sticker; Power Cable; Remote Control; Setup Manual |
| Warranty | 3 years warranty incl. backlight; on-site service; optional 4. + 5. year warranty extension 1 |
| Operating Hours | 16/7 |
| External Control | ASCII Control Commands; HDMI CEC; Scheduled Timer |
